Copyright © 2010, Juniper Networks, Inc. 33
APPLICATION NOTE - Branch Office Connectivity Guide
Appendix C Products
Product Tables
Product/Technology Type A - Basic Type B - Optimized Type C – Critical
Firewall/VPN with full UTM
features (antivirus, anti-
phishing, anti-spyware, anti-
adware, anti-keylogger, anti-
spam, Web filtering)
Uses integrated
security functionality in
the SSG Series
Uses integrated
security functionality in
the SSG Series
Uses integrated
security functionality in
the SSG Series
Routing Uses integrated routing
functionality in the SSG
Series
Uses integrated routing
functionality in the SSG
Series
Uses J Series
Unified threat management Integrated into
SSG Series
Integrated into
SSG Series
Integrated into
SSG Series
Unified access control Policy enforcement is integrated into the SSG Series firewall. Juniper
Networks IC Series Unified Access Control Appliances are typically deployed
at the data center or headquarters location.
WAN application acceleration — — WX Series/WXC Series
Centralized management NSM for security
Juniper Networks WX Central Management System for WAN application
acceleration
Junos Scope Software for enterprise routers
Centralized reporting
& control
Junos OS
Product Recommendation Based On Branch Office Profile
Small Small-
Medium
Medium Medium-Large Large
10 Users/BB 50 Users/T1-E1 100 Users/
MLPPP-MLFR
250 Users/
MLPP-MLFR
500 Users/DS3
Type A - basic SSG5 SSG20 SSG140 SSG320/350 SSG520 or
ISG1000
Type B - optimized 2 x SSG5 2 x SSG20 2 x SSG140 2 x SSG320/350 2 x SSG520 or
2 x ISG1000
Type C - critical 2 x SSG140 and
2 x J2350
2 x SSG320/350
and 2 x J2350
2 x SSG520 or
2 x ISG1000 and
2 x J4350
Partner Products
Symantec
Juniper Networks has teamed with Symantec Corporation to leverage its market-leading anti-spam solution for
Juniper’s small to medium office platforms to help slow the flood of unwanted email and the potential attacks they
carry. Part of a complete set of UTM features available on Juniper Networks firewall/VPN gateway, the anti-spam
engine filters incoming email for known spam and phishing users to act as a first line of defense. When a known
malicious email arrives, it is blocked and/or flagged so that the email server can take an appropriate action. Anti-
spam is available on the SSG Series as an annually licensed feature.
