Quick Start Owner manual

Quick Start Guide
Get your Field PC up and running!
Use edge of a key or screwdriver
to open battery compartment.*
1
Insert the battery pack(s) so
battery contacts match up.
2
Re-attach battery door.
3
Plug battery charger into wall
outlet, then into the unit.
4
Charge for 4 hours per battery.
5
*The hand strap does not need to be removed to open battery compartment.
1 Stylus
2 USB Client
3 12V DC jack
4 USB Host
5 9-pin serial port (2)
6 Top bumper
7 Touchscreen/Display
The anatomy of your Field PC
8 Power button
9 Expansion pod door
10 Hand strap
11 Battery door
12 Battery door latches
13 Bottom bumper
6
7
12
8
9
11
5
4
2
1
3
13
part# 20197_00
• Desktop Utilities
• User manual
Documentation CD
ULTRA-RUGGED
FIELD PC
4 hours
10
© Copyright 07-2009 Juniper Systems, Inc. All rights reserved.
Follow on-screen instructions to
set up device.
6
