Quality of service (QoS) per channel: weighted round-robin (WRR), random early detection
(RED), weighted random early detection (WRED)
■
SNMP: T1 MIB and DS0 MIB
■
Dynamic, arbitrary channel configuration
■
Full bit error rate test (BERT) patterns at T1 and DS0 levels
■
Encapsulations:
■
High-Level Data Link Control (HDLC)
■
Frame Relay
■
Circuit cross-connect (CCC)
■
Translational cross-connect (TCC)
■
Point-to-Point Protocol (PPP)
Software features
■
120-ohm RJ-48C connector (female)Cables and connectors
One tricolor per port:
■
Off—Not enabled
■
Green—Online with no alarms or failures
■
Amber—Online with alarms for remote failures
■
Red—Active with a local alarm; router has detected a failure
LEDs
■
Alarm indication signal (AIS)
■
Remote defect indication (RDI)
■
Loss of frame (LOF)
■
Loss of signal (LOS)
■
Bipolar violation (BPV)
■
Excessive zero (EXZ)
■
Line code violation (LCV)
■
Error seconds (ES)
■
Severely errored seconds (SES)
■
Severely errored frames (SEF)
■
Bit error event (BEE)
Alarms, errors, and
events
■
Layer 2 per-queue and per-channel packet and byte counters
■
24–hour history or error counter updated at 15–minute intervals
Instrumentation
(counters)
