FPCs Supported
T1600 routing nodes support the FPCs listed in Table 2 on page 6.
Table 2: FPCs Supported by the T1600 Routing Node
First JUNOS
Release
Maximum
Throughput per
FPC
Maximum Number
of PICs
FPC Model
Number
FPC NameFPC Type
6.34 Gbps4T640-FPC1-EEnhanced FPC11
7.44 Gbps4T640-FPC1-E2Enhanced II FPC11
5.316 Gbps4T640-FPC2FPC22
6.316 Gbps4T640-FPC2-EEnhanced FPC22
7.416 Gbps4T640-FPC2-E2Enhanced II FPC22
5.340 Gbps4T640-FPC3FPC33
6.340 Gbps4T640-FPC3-EEnhanced FPC33
9.040 Gbps4T640-FPC3-ESEnhanced Scaling
FPC3
3
7.540 Gbps1T640-FPC4-EST640 Enhanced
Scaling FPC4
4
8.5100 Gbps2T1600-FPC4-EST1600 Enhanced
Scaling FPC4
4
