Table 23: Optical Interface for 10-Gigabit Ethernet IQ2 PICs
10-GBase-Z10-GBase-E10-GBase-L10-GBase-SParameter
XFP-10G-Z-OC192-LR2XFP-10G-E-OC192-IR2XFP-10G-L-OC192-SR1XFP-10G-STransceiver model
number
Single-modeSingle-modeSingle-modeMultimodeOptical interface
XFPXFPXFPXFPTransceiver type
Multivendor
agreement
IEEE 802.3ae—2002IEEE 802.3ae—2002IEEE 802.3ae—2002Standard
9/125 SMF cable:
49.6 miles/80 km
9/125 SMF cable:
24.8 miles/40 km:
Distances greater than
30 km are considered
to be engineered
links.
9/125 SMF cable:
6.2 miles/10 km
50/125 MMF cable,
2000 MHz-km:
984 feet/300 m
50/125 MMF cable,
500 MHz-km:
269 feet/82 m
50/125 MMF cable,
400 MHz-km: 217
feet/66 m
62.5/125 MMF cable,
200 MHz-km: 108
feet/33 m
62.5/125 MMF cable,
160 MHz-km: 85
feet/26 m
Maximum distance
1530 through
1565 nm
1530 through
1565 nm
1260 through
1355 nm
840 nm through 860
nm
Transmitter wavelength
0 through 4 dBm–4.7 through 4 dBm–8.2 through 0.5 dBm–4.5 through –1 dBmAverage launch power
–24.0 through –7.0
dBm
–15.8 through –1.0
dBm
–14.4 through 0.5
dBm
–9.9 through –1.0
dBm
Average receive power
–7 dBm–1.0 dBm0.5 dBm–1.0 dBmReceiver saturation
–24 dBm–15.8 dBm–14.4 dBm–9.9 dBmReceiver sensitivity
