SONET/SDH OC192c/STM64 PICs with XFP
Left: 1-port SONET/SDH OC192c/STM64 PIC; Right: 4-port SONET/SDH OC192c/STM64 PIC
■
1-port: JUNOS 8.5 and later (Type 3)
■
4-port: JUNOS 8.5 and later (Type 4)
Software release
■
One or four OC192 ports
■
4-port OC192 PIC with XFP: four OC192 links can be aggregated into one OC768 link or
two OC256 links. The four fiber links should be on the same fiber path or the same fiber.
■
Power requirement:
■
1-port: 0.52 A @ 48 V (25 W)
■
4-port: 1.11 A @ 48 V (53.1 W)
Description
■
Multiplexing and demultiplexing
■
Rate policing on input
■
Rate shaping on output
■
Packet buffering, Layer 2 parsing
Hardware features
