6 Instrument description

Nominal

position

unrestricted

Weight approx. 0.2 kg

Capillary and

probe material

Minimum

bending radius

of capillary

5mm

Mean

ambient

temperature

error

in % of scale span, referred to the limit value.

A deviation of the ambient temperature at the switch head and/or the capillary

from the +22 °C calibration ambient temperature produces a shift in the

switching point:

higher ambient temperature = lower switching point

lower ambient temperature = higher switching point

Temperature

compensation

(extra code 707)

Please see the diagram in Data Sheet 602021 for details.

End of scale Capillary Probe

up to +200 °C copper, Mat. Ref. Cu-DHP

1.5 mm diameter

copper, Mat. Ref. Cu-DHP

brazed

up to +350 °C copper, Mat. Ref. Cu-DHP

1.5 mm diameter

stainless steel,

Mat. Ref. 1.4571

brazed

up to +500 °C stainless steel,

1.5 mm diameter

stainless steel,

Mat. Ref. 1.4571

welded

at extra cost

up to +350 °C stainless steel,

1.5 mm diameter

stainless steel,

Mat. Ref. 1.4571

welded

For temperatures with end of scale / limit value

< +200 °C ≥ +200 °C ≤ +350 °C ≥ +400 °C ≤ +500 °C

TR, TW, TB STW

STB

TR, TW, TB STW, STB TR, TW, TB

STW, STB

Switching differential in %

1 / 2.5 5 7 7 / - - 1 / 2.5 5 7 / - - 3.5 6 10

Ambient temperature effect due to the switch head, % per °C

0.15 0.26 0.34 0.43 0.12 0.21 0.35 0.12 0.17 0.24

Ambient temperature effect due to the capillary, % per °C per meter

0.05 0.09 0.04 0.07 0.05
