Operating Manual Owner's manual

3 Mounting
16
3.4.1.2 Stainless steel pockets 20, 22, 40 and 41/42
Loading
3.4.1.3 Brass pockets 20 and 40
Loading
Material of tube and nipple: stainless steel (1.4571)
Tem p er a t ure
Tube diameter D
8 x 0.75 mm
or conical
10 x 0.75 mm 15 x 0.75 mm
Max. permissible pressure
100°C 92 bar 74 bar 50 bar
150°C 88 bar 71 bar 48 bar
200°C 83 bar 67 bar 45 bar
300°C 72 bar 58 bar 39 bar
400°C 67 bar 54 bar 36 bar
Material of tube and nipple: CuZn
Tem p er a t ure
Tube diameter D
8 x 0.75 mm 10 x 0.75 mm 15 x 0.75 mm
Max. permissible pressure
100°C 50 bar 40 bar 27 bar
150°C 48 bar 39 bar 26 bar
