3.4 Permissible loading on the pocket
3.4.1 Pockets 20, 22/23, 40 and 41/42
3.4.1.1 Steel pockets 22, 23, 32, 41, 42 and 45
Materials Tube: St35.8 I
Screw-in nipple up to 300°C: Steel 1.0038
Weld-in nipple: Steel 1.5415
Loading
A
The values given below refer to the maximum loading on the probe mounting
concerned. The maximum pressure which can be sealed depends on the
mounting conditions and may possibly be lower.
Tem p er a t ure
Tube diameter D
8 x 0.75 mm
or conical
10 x 0.75 mm 15 x 0.75 mm
Max. permissible pressure
100°C 89 bar 72 bar 48 bar
150°C 83 bar 67 bar 45 bar
200°C 78 bar 63 bar 42 bar
300°C 59 bar 47 bar 32 bar
350°C 50 bar 40 bar 27 bar
