Order
code ( 7 ) Ø Process connection (PC)
a
a
For the description and particularities refer to data sheet 608730.
66 mm
88 mm
10 10 mm
11 11 mm
12 12 mm
( 8 ) Thread type of process connection (PA)
a
000 Without thread (for TA 01 and TF 11)
103 Screw connection G 3/8
104 Screw-connection G 1/2
105 Screw-connection G 3/4
114 Screw-connection M 10 x 1 (only for TA 23)
( 9 ) Material, probe / support tube
a
26 Stainless steel (CrNi, 1.4571)
96 Copper (Cu) / Brass (CuZn) (up to 200°C)
95 Stainless steel (CrNi, 1.4571) - probe / Brass (CuZn) - support tube from
250°C)
( 10 ) Material of process connection (PA)
a
00 Without (only TF 01 and TF 11)
26 Stainless steel (CrNi, 1.4571)
46 Brass (CuZn)
( 11 ) Fitting length, process connection (PA)
a
(dimension "EL“ or "S“)
0 Minimum fitting length TF 11 (active probe dimen-
sion)
50 50 mm
100 100 mm
150 150 mm
200 200 mm
. . . Special length (specifications in plain text - 50 mm steps)
