Admissible load at the sheath
Sheaths 20 (U), 22 (US), 30 (UZ), 32 (UZS),
40 (E), 41 (ES), 45 (EZS) and 46 (EZS)
The following values describe the maximum capacity of the corresponding connection type.
The maximum pressure sealable depends on the fitting conditions and may be lower.
Sheath made of steel 22, 23, 32, 41, 42, 45 and 46 (Discontinued types: 20, 30, 32 and 40)
Sheath made of stainless steel
Sheath made of brass
Material Tube Screw-in nipples Welding nipples
St 35.8 I Steel 1.0038 Steel 1.5415
Capacity Temperature Pipe diameter
8 x 0.75 mm or conical 10 x 0.75 mm 15 x 0.75 mm
Maximum admissible pressure
100°C 89 bar 72 bar 48 bar
150°C 83 bar 67 bar 45 bar
200°C 78 bar 63 bar 42 bar
300°C 59 bar 47 bar 32 bar
350°C 50 bar 40 bar 27 bar
max. admissible
operating
temperature
Tube Nipple max. admissible operating temperature*
static load without load
St 35.8 I
Screw-in nipples +300°C
+530°C
Welding nipples +450°C
* observe the max. admissible probe temperature of the respective thermostat version.
* For operating temperatures > +420°C: observe the operating life of 200,000 h at a static load TRD508.
* Sheath "21" (UO) and "31" (UZO): Use only in pressureless medium.
Material Pipe and nipple: Stainless steel (1.4571)
Capacity Temperature Pipe diameter
8 x 0.75 mm or conical 10 x 0.75 mm 15 x 0.75 mm
Maximum admissible pressure
100°C 92 bar 74 bar 50 bar
150°C 88 bar 71 bar 48 bar
200°C 83 bar 67 bar 45 bar
300°C 72 bar 58 bar 39 bar
400°C 67 bar 54 bar 36 bar
max. admissible
operating
temperature*
static load +400°C without load +530°C
* observe the max. admissible probe temperature of the respective thermostat version.
Material Pipe and nipple: CuZn, nickel plated
Capacity Temperature Pipe diameter
8 x 0.75 mm 10 x 0.75 mm 15 x 0.75 mm
Maximum admissible pressure
100°C 50 bar 40 bar 27 bar
150°C 48 bar 39 bar 26 bar
max. admissible
operating
temperature*
+150°C
* observe the max. admissible probe temperature of the respective thermostat version.
