2011-07-01/00073261
Page 3/8
Screw-connections
Order code: 1 2 3
Process connection Thread G Material Remarks
Double screw-con-
nection
"60“
(Q)
for retrofitting to
the capillary.
Probe temperature
max. +200°C.
( 1 ) Washer
( 2 ) Seal
G
1
/
2
L
1
=14
27
G
3
/
8
L
1
=12
22
CuZn (brass)
CrNi (stainless steel)
Suitable for probe Ø up to 8 mm.
Use only in pressureless medium.
Order code: 606710-60 13 12 46 20
Stuffing box
screw-connection
"65“
(V)
for retrofitting to
the capillary.
Probe temperature
max. +200°C.
( 1 ) Washer
( 2 ) Seal
M 14 x 1
19
CuZn (brass)
CrNi (stainless steel)
Suitable for probe Ø up to 6 mm.
Use only in pressureless medium.
Order code: 606710-65 35 46 20
123
Order code: 606710-. . - . . - . .
Order example: 606710-60 -13-20
G
L1
(1)
(1)
(2)
Ø
G
L1
(1)
(1)
(2)
(2)
Ø
