4 Electrical connection
21
2013-04-01
10 Relay output alarm (zero-current state)
Relay (changeover contact) with fuse cut-out
11 Relay output for pre-alarm (KV)
Relay (changeover contact)
V
Caution
The pre-alarm relay output is not part of the
safety function!
Legend Comment Screw terminals Screw terminals
Internal circuitry
S
P
11
12 13
Ö
