3 Mounting
15
2013-04-01
3.5 Galvanic isolation
3.6 Use of the setup interface
- The USB setup interface is only designed for service use over a limited period (such as the transfer of setup data or during
startup).
- The USB setup interface is not suited for perpetual operation in a hard-wired plant because the monitoring function is de-
activated during data transfer with the setup program!
(1) Analog inputs
(3) Binary input
(5) Setup interface
(6) Display
(7) Analog output
(8) Voltage supply
(2) Relay output alarm
(4) Pre-alarm relay output
»
3700 V AC
»
3700 V AC
(1)
(2)
(4)
(3)
(5)
(8)
(6)
(7)
»
3700 V AC
50 V DC
»
