14 Information for devices with extra code 062 GL
131
2013-04-01
14 Information for devices with extra code 062 GL
The following information supplements or replaces the existing specifications.
14.1 Technical data
Ambient conditions according to application category C for closed areas
Inspection basis: GL design specifications & directives:
EMC 1
Software requirement class: 4
14.2 Alarm messages
v Chapter 11 "Alarm messages"
14.3 Locks
The configuration level can be locked with a code.
v Chapter 8.6.9 "Code"
Intentional or unintentional adjustments are not possible without additional measures.
v Chapter 5.8 "Seal device"
Temperature 0 to 55°C
Relative air humidity ≤ 100 % rh
Vibration ≤ 0.7 g
