12 Error messages
2013-04-01
126
Watchdog
1
Internal A watchdog reset has occurred.
Acknowledgement is possible.
Overvoltage
1
Internal The uncontrolled secondary supply voltage is too high. Acknowledgement is
possible.
Frequency
1
Internal Error of independent time base.
Acknowledgement is possible
EEPROM defective
1
Internal Error during internal communication with the EEPROM.
Acknowledgement is possible.
Stack
1
Internal Error in the memory area reserved for the stack.
Acknowledgement is not possible until it is within the valid range again.
AD converter
1
Internal Error during internal communication with the A/D converter.
Acknowledgement is possible
Simulation
1
Internal Error during measured value simulation.
Acknowledgement is possible.
Zero point
1
Internal The zero point voltage of the A/D converter is too low.
Acknowledgement is possible.
Limit value Plant The configured limit value has been exceeded or has not been met.
Error display (Err) Origin Cause/remedy
