10 Setup program
2013-04-01
122
5
h Transfer the data to the device
An overview of the parameters appears
6
h Following successful data transfer disconnect the USB
connection.
7 The device now shows a pressure between 0 and 500 Pa.
If the pressure falls below 200 Pa, the alarm relay output is
switched off.
Step Action Description
