9 Technical data
115
2013-04-01
Note: because of the high response accuracy, only use thermowells (immersion sleeves) that are included in the scope of delivery.
Current type designation Probe type Temperature range Nom. length mm Process connection
RTD temperature probe data sheet 902006
902006/53-505-2003-1-12-190-815/922
2×Pt100
-40 to +400 °C 190
902006/53-507-2003-1-12-100-815/922 2 × Pt100
(arranged beneath
each other
in the sheath)
-40 to +480 °C 100
902006/53-507-2003-1-12-160-815/922 160
902006/53-507-2003-1-12-190-815/922 190
902006/53-507-2003-1-12-220-815/922 220
902006/53-507-1003-1-12-100-815/922 1 × Pt100 -40 to +480 °C 100 Weldable sleeve
902006/53-507-1003-1-12-160-815/922 160
902006/53-507-1003-1-12-220-815/922 220
902006/53-505-1003-1-12-190-815/922 1 × Pt100 -40 to +400 °C 190
902006/53-505-3003-1-12-100-815/922 3 × Pt100 -40 to +400 °C 100
902006/53-505-3003-1-12-160-815/922 160
902006/53-505-3003-1-12-220-815/922 220
902006/40-226-1003-1-12-220-815/922 1 × Pt100 -170 to +480 °C 220 Weldable sleeve
902006/40-226-1003-1-12-160-815/922 160
902006/40-226-1003-1-12-100-815/922 100
Thermocouples data sheet 901006
901006/53-543-1042-12-220-815/922 1 × Fe-CuNi type "L" -35 to 480 °C 220 Weldable sleeve
901006/53-543-2042-12-220-815/922 2 × Fe-CuNi type "L" 220
