9 Technical data
2013-04-01
114
9.14 Probes for water and oil
Note: because of the high response accuracy, the use of thermowells (immersion sleeves) is not admissible.
Current type designation Probe type Temperature range Nom. length mm Process connection
RTD temperature probe data sheet 902006
902006/10-226-1003-1-9-250-104/922 1 × Pt100 -40 to +480 °C 250 Screw connection G1/2
902006/10-226-2003-1-9-250-104/922 2 × Pt100 250
902006/54-227-2003-1-15-710-254/922 2 × Pt100 -170 to 550 °C 65 to 670 Displaceable
screw connection G1/2
902006/54-227-1003-1-15-710-254/922 1 × Pt100 65 to 670
902006/10-402-1003-1-9-100-104/922 1 × Pt100 -170 to 400 °C 100 Screw connection G1/2
902006/10-402-2003-1-9-100-104/922 2 × Pt100 100
Thermocouples data sheet 901006
901006/54-544-2043-15-710-254/922 2 × NiCr-Ni, type "K" -35 to 550 °C 65 to 670 Displaceable
screw connection G1/2
901006/54-544-1043-15-710-254/922 1 × NiCr-Ni, type "K" 65 to 670
901006/54-544-2042-15-710-254/922 2 × FeCuNi, type "L" 65 to 670
901006/54-544-1042-15-710-254/922 1 × FeCuNi, type "L" 65 to 670
