9 Technical data
2013-04-01
112
9.13 Probes for the operating medium air
Note: because of the high response accuracy, the use of thermowells (immersion sleeves) is not admissible.
Current type designation Probe type Temperature range Nom. length mm Process connection
RTD temperature probe data sheet 902006
902006/65-228-1003-1-15-500-668/922 1 × Pt100 -170 to +700 °C 500
902006/65-228-1003-1-15-710-668/922 710
902006/65-228-1003-1-15-1000-668/922 1000
902006/55-228-1003-1-15-500-254/922 1 × Pt100 -170 to +700 °C 500
902006/55-228-1003-1-15-710-254/922 710
902006/55-228-1003-1-15-1000-254/922 1000
902006/65-228-2003-1-15-500-668/922 2 × Pt100 -170 to +700 °C 500 Stop flange
displaceable
902006/65-228-2003-1-15-710-668/922 710
902006/65-228-2003-1-15-1000-668/922 1000
902006/55-228-2003-1-15-500-254/922 2 × Pt100 -170 to +700 °C 500 Displaceable
screw connection G1/2
902006/55-228-2003-1-15-710-254/922 710
902006/55-228-2003-1-15-1000-254/922 1000
Thermocouples data sheet 901006
901006/65-547-2043-15-500-668/922 2 × NiCr-Ni, type "K" -35 to +800 °C 500 Stop flange
displaceable
901006/65-547-2043-15-710-668/922 710
901006/65-547-2043-15-1000-668/922 1000
901006/65-546-2042-15-500-668/922 2 × Fe-CuNi, type "L" -35 to +700 °C 500
901006/65-546-2042-15-710-668/922 710
901006/65-546-2042-15-1000-668/922 1000
901006/66-550-2043-6-500-668/922 2 × NiCr-Ni, type "K" -35 to +1000 °C 500
901006/66-550-2043-6-355-668/922 355
901006/66-550-2043-6-250-668/922 250
901006/66-880-1044-6-250-668/922 1 × PT10Rh-PT, type "S" 0 to 1300 °C 250
901006/66-880-1044-6-355-668/922 355
901006/66-880-1044-6-500-668/922 500
901006/66-880-2044-6-250-668/922 2 × PT10Rh-PT, type "S" 0 to 1300 °C 250 Stop flange
displaceable
901006/66-880-2044-6-355-668/922 355
901006/66-880-2044-6-500-668/922 500
