9 Technical data
107
2013-04-01
9.5 Measuring circuit monitoring
9.6 Voltage supply
RTD temperature probe in 3-
wire circuit and
dual thermocouples
Thermocouples Current 4 to 20 mA
Overrange
and underrange
Is detected
LEDs K1, K2, KD, and KV are lit;
">>>>" flashes in the display for overrange, "<<<<" for underrange
Probe and cable break Is detected
LEDs K1, K2, KD, and KV are lit;
">>>>" flashes in the display; alarm relay output is inactive
LEDs K1, K2, KD, and KV are lit;
">>>>" flashes in the display;
alarm relay output is inactive
Probe short circuit Is detected
LEDs K1, K2, KD, and KV are lit;
"<<<<" flashes in the display;
alarm relay output is inactive
Is detected by difference
monitoring
of the analog inputs
v Chapter 8.3.6 "Limit
value difference, hysteresis"
LEDs K1, K2, KD, and KV are lit;
"<<<<" flashes in the display;
alarm relay output is inactive
Voltage supply AC/DC 20 to 30 V, 48 to 63 Hz
AC 110 to 240 V, +10/-15 %, 48 to 63 Hz
Power consumption 12 VA
Power loss < 12 W
