9 Technical data
2013-04-01
106
9.2 Analog output
9.3 Binary input
9.4 Relay outputs
Signal type Accuracy Residual ripple Load influence Temperature influ-
ence
Load
resis-
tance
Current 4 to 20 mA
≤ 0.5 % ±0.5 % at 300 Ω ±0.05 mA / 100 Ω 150 ppm/K ≤ 500 Ω
0to20mA
Voltage 2 to 10 V
≤ 0.5 % ±0.5 % ±15 mV 150 ppm/K ÷ 500 Ω
0to10V
Connection Function
1 potential-free contact Unlocking, key lock, level inhibit can be configured
Relay output KV Relay (changeover contact) without contact protection
30000 switching operations at a switching capacity of AC 250 V/3 A, 50 Hz (resistive load)
or up to DC 30 V/3 A. Minimum current: DC 12 V/100 mA.
Relay output alarm Relay (changeover contact)
Contact protection circuit: fuse cut-out 3.15 AT, installed in the N/O contact arm
30000 switching operations at a switching capacity of AC 230 V/3 A, 50 Hz (resistive load)
or up to DC 30 V/3 A. Minimum current DC 12 V/100 mA.
