8 Configuration level
103
2013-04-01
8.7 Service
Parameter Comment
Value range
(factory setting in bold)
8.7.1 Limit switching cycle
Limit value for relay switching cycles
Here, the limit value for the admissible relay switching
cycles is set.
If the counter value for Current switching cycles is
greater than this value, the display values flash and the
alarm relay output drops out.
If "0" is set the function is inactive.
0 to 99999
8.7.2 Current switching cycles
Relay switching cycle counter
Here, the switching cycles for the relay are only count-
ed if the top limit value for relay switching cycles is
not set to "0" and is thus inactive.
The value can then be adjusted as required and there-
fore adapted accordingly to the plant.
The switching cycle counter remains at 99999.
0 to 99999
8.7.3 Operating hours
Operating hours counter
The counter adds up the operating hours during which
the device was connected to the voltage supply.
The value cannot be changed and can be used as a
measure of how long the device was actually in opera-
tion after leaving the factory.
0 to 99999
