8 Configuration level
101
2013-04-01
8.6 Display/operation
Parameter Comment
Value range
(factory setting in bold)
8.6.1 Language
German German, English, French
English
French
8.6.2 Unit
A unit for the measured value can be assigned here. °C, °F, %, te x t
°C
°F
%
Tex t:
Via the setup program, 2 characters can be entered
here for another unit, e.g. Pa (Pascal).
8.6.3 Decimal place
No decimal place No decimal place,
One decimal place
One decimal place
8.6.4 Normal display
This sets the view that appears after the voltage supply
is switched on.
v Chapter "Operating overview"
Main measured value,
measured values, limit
value, pre-alarm, difference
Main measured value
Measured values
Limit value
Pre-alarm
Difference
A
If the unit is changed to °F, the mea-
sured value is converted.
All other values referring to the mea-
sured value (e.g. limit value) remain
unchanged.
