MA
47
Warning:
For supervised or unsupervised operation with the “AUTOSTART“ function
avoid any hazardous situation to persons or property
Take care to fully observe the safety and warning functions of the circulator.
9.2.4. Reset - Factory setting
>YES< resets all values to factory setting.
A >rSt< RESET can be effected in the > < mode only.
Switch off the circulator by pressing the key and call up the
menu CONFIGURATION.
During the message – init - all parameters are reset to factory
settings
9.3. MENU Control parameters – Xp, Tv, Tn
Menu level 1
In most cases the control parameters preset in the factory are adequate
for achieving an optimum temperature sequence.
The control parameters allow adjustment to special control processes..
Level 2 Parameter level
Press the key if a parameter is to be
retained. Correction function for parameters or
values (prior to OK)
0.1 … 99.9
Proportional range >Xp<
• The parameter flashes, switch by pressing
and
3 … 9999
Reset time >Tn< (Integral component)
• The parameter flashes, switch by pressing
and
0 … 999
Lead time >Tv< (Differential component)
• The parameter flashes, switch by pressing
and
