Datasheet

104104104
SAN CONNECTOR
SAN-002T-0.8A
SAN-002T-0.8K
AP-K2N
MKS-LS・MKS-L
*MKS-SC
MK/SAN-002-08
SC/SAN-002-08
APLMK SAN002-08
APLSC SAN002-08
Material and Finish
Model No.
Applicable wire
Q
’ ty / reel
mm
2
AWG #
Insulation O.D.(mm)
14,000
Brass, tin-plated (reflow treatment)
SAN-002T-0.8A
SAN-002T-0.8K
A
B
0.05∼0.22 30∼24 0.9∼1.3
Type
1 131415
JST
B
A
2.0
5.65
3.25
Circuits Model No.
Dimensions (mm)
Q
' ty /
bag
AB
Material
PA 66, UL94V-0, yellow
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2P-SAN
3P-SAN
4P-SAN
5P-SAN
6P-SAN
7P-SAN
8P-SAN
9P-SAN
10P-SAN
11P-SAN
12P-SAN
13P-SAN
14P-SAN
15P-SAN
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
5.2
7.2
9.2
11.2
13.2
15.2
17.2
19.2
21.2
23.2
25.2
27.2
29.2
31.2
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
2.0
1.6
0.9
3.1
9.0
1.8
0.9
3.1
9.0
RoHS compliance
Note: Contact JST if you require shielded wires, thin wires or other special
wires.
Type A
Type B
RoHS compliance
<For reference> As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex. 2P-SAN-o-
(blank)…yellow K…black W…white R…red
Contact
Crimping
machine
Crimp applicator Dies Crimp applicator with dies
Applicator
Note: *Strip-crimp applicator
Contact
Housing
