(V BAT_IN = 3.0V)
I OH High-level source current, V OH = 2.4 6 mA
I OL Low-level sink current, V OH = 0.4 6 mA
Pin internal Pull up and Pull down (25°C)
))
)
PARAMETER MIN NOM MAX UNIT
I OH Pull-Up current, V OH = 2.4
(V BAT_IN = 3.0V)
5 10 μA
I OH Pull-Down current, V OL = 0.4
(V BAT_IN = 3.0V)
5 μA
3.4. WLAN RF Specifications
 WLAN Receiver Characteristics
Parameter Condition (Mbps) Min Typ Max Units
Sensitivity
(8% PER for 11b rates, 10% PER for
11g/11n rates)(10% PER)
1 DSSS -92.5
dBm
11 CCK -86.3
6 OFDM -86.1
54 OFDM -71.2
MCS0 -84.1
MCS7 -67.3
Maximum input level (10% PER)
802.11b -4.0
802.11g -10.0
 WLAN Transmitter Characteristics
Parameter Condition Min Typ Max Units
Maximum RMS output power
measured at 1 dB from IEEE spectral
mask or EVM
1 DSSS 16.0
dBm
11 CCK 16.0
6 OFDM 15.5
54 OFDM 12.5
MCS0 15.0
MCS7 11.0
Output power accuracy -2 2 dB
Transmit center frequency accuracy -25 25 ppm
(1) Channel-to-channel variation is up to 2dB. The edge channels (2412 and 2472MHz) have
reduced TX power to meet FCC emission limits.
