Mid Span Slitters | Data Sheet
Replacement Cartridges
These PATENTED tools are designed to open fiber jackets and loose buffer tubes to provide easy fiber access. The buffer tube slitting
is done without damage to the fiber. Blades are replaceable.
Simple to use:
• Select the correct groove. Grooves are marked with the recommended cable size
• Place the cable in the groove to be used
• Note: The arrow on the top of the tool indicates the pulling direction and the line indicates the blade location
• Close the tool making sure lock is engaged and pull to slit the cable
SPECIFICATIONS MS-6 MS-26
DESCRIPTION
Mid Span Slitter (1.2mm-3.3mm) Mid Span Slitter (2.9mm-6.8mm)
NO. OF PRECISION GROOVES
6 5
GROOVE SIZES (MM)
1.2-1.5, 1.5-1.8, 1.8-2.1, 2.1-2.5, 2.5-2.9, 2.9-3.3 2.9-3.6, 3.6-4.4, 4.4-5.2, 5.2-6.0, 6.0-6.8
REPLACEMENT CARTRIDGE
MSB-1533 MSB-2968
JONARD P/N DESCRIPTION
MSB-1533
Replacement Blades for MS-6
MSB-2968
Replacement Blades for MS-26
