33. DEFAULTS Set various system conguration settings to the factory default.
Press EXECUTE to enter the menu.
Press MENU ( ) to scroll through and select which item(s) to default.
3ØPATCH? Sets the dimmer phase patch to AAAABBBBCCCC. This is the default setting.
1ØPATCH? Sets the dimmer phase patch to AAAAAACCCCCC.
CURVES? Sets all 12 or 24 dimmer curve proles to Square Law curve.
V-LIMIT? Sets the output voltage limit to full (127.5 or 255) on all 12 or 24 dimmer outputs.
FD-TIME? Sets the fade time at 5 seconds for all 12 or 24 scenes.
2 ROOM? Sets the two room assignment to room “A” on all 12 or 24 dimmer outputs.
D-PATCH? *Clears the dimmer to channel patch and congures it for 1:1 operation.
12 PACK? **Clears the DC-PATCH and congures it for 1:1 operation for 12 dimmers.
6 PACK? **Clears the DC-PATCH and congures it for 1:1 operation for 6 dimmers.
SURE??? Press EXECUTE to select the item to default. Are you sure?
DONE!!! Press EXECUTE to set the selected default.
Press ESCAPE or RESET to exit the menu.
NOTE: * Applies to the DPC-24 only. ** Applies to the DPC-12 only, and provides
a quick way to congure the control module for sequential DMX control of
either a 12 or 6 dimmer circuit CD80 pack. When a DPC-12 is congured
for controlling a 6 dimmer circuit CD80 pack, local button LED’s 1 and 2
indicate control for dimmer 1, local button LED’s 3 and 4 indicate control for
dimmer 2, local button LED’s 5 and 6 indicate control for dimmer 3, local
button LED’s 7 and 8 indicate control for dimmer 4, local button LED’s 9 and
10 indicate control for dimmer 6 and local button LED’s 11 and 12 indicate
control for dimmer 6.
34. LED INT Set the LED intensity for the programming switches.
Press EXECUTE to enter the menu.
LEV:100% Press MENU ( ) to adjust the LED intensity from 0% to 100%.
LEV:050% Press MENU ( ) and MENU ( ) at the same time to toggle back to 50%.
Press ESCAPE to exit the menu and save the desired setting.
Press RESET to exit the menu without saving.
The menu will automatically timeout after 2 minutes of inactivity and save.
35. LCD VIEW Adjust the contrast of the LCD Display for optimum viewing.
Press EXECUTE to enter the menu.
ADJUST Press MENU ( ) to adjust the LCD contrast.
Press ESCAPE to exit the menu and save the desired LCD view.
Press RESET to exit the menu without saving.
The menu will automatically timeout after 2 minutes of inactivity and save.
