www.johnsonsystems.com
20
WILL Firmware update in progress.
AUTO Firmware update in progress.
RESTART Firmware update in progress.
PLEASE Firmware update in progress.
WAIT.... When rmware update is complete the RUN LED ashes and system restarts.
NO MEM! Displayed if an EEPROM memory module is not detected.
WRONG Displayed if the wrong type (parameter) of EEPROM memory module detected.
MEM TYPE Displayed if the wrong type (parameter) of EEPROM memory module detected.
WRONG Displayed if the wrong product type of EEPROM memory module detected.
PRODUCT Displayed if the wrong product type of EEPROM memory module detected.
CRC ERR! Displayed if the CRC test fails and the EEPROM memory module is defective.
WARNING: Do not reset or turn the power off while the rmware is being updated.
Doing so will cause unrecoverable loss of rmware data that is being
loaded into the DPC-24/12 microcontroller.
30. RESTORE Restore parameters saved in the EEPROM memory module.
All of the conguration setting parameters can be restored from an EEPROM memory
module if they have been inadvertently changed or corrupted. This feature can
also be used to load conguration setting parameters into a different or new control
module. This reduces the conguration time for multi-system applications that require
similar settings or when a replacement control module is required.
Press EXECUTE to enter the menu.
DISABLED This menu is disabled to help prevent inadvertent changes. Proceed to enable.
ENABLED Press and hold MENU ( ) and MENU ( ) at the same time for 4-5 seconds.
MEMCHECK Automatically checks the EEPROM memory module for parameter type.
OKAY.... The EEPROM memory module has been veried for parameter type.
PROCEED? Press EXECUTE to proceed.
SURE ??? Press EXECUTE to proceed.
CRC-TEST Automatically does a CRC test on the parameter code in the EEPROM.
WAIT CRC test in progress.
VERIFY CRC test in progress.
DONE!! CRC test is done and the parameter restore automatically begins.
WILL Parameter restore in progress.
AUTO Parameter restore in progress.
RESTART When parameter restore is complete, the system restarts.
SERIAL # Displayed when the silicone serial number on the EEPROM memory module is a
mismatch with the silicone serial number on the DPC-24/12 microcontroller.
PROCEED? Press EXECUTE to proceed.
NO MEM! Displayed if an EEPROM memory module is not detected.
WRONG Displayed if the wrong type (parameter) of EEPROM memory module detected.
MEM TYPE Displayed if the wrong type (parameter) of EEPROM memory module detected.
WRONG Displayed if the wrong product type of EEPROM memory module detected.
PRODUCT Displayed if the wrong product type of EEPROM memory module detected.
ERROR Displayed when an error occurs. Waits for key press to restart RESTORE.
