9. Technical Specifications
Laser Wavelength 635nm±10nm
Laser Classification Class IIIa
Maximum Power Output ≤5mW
Accuracy ±1/8"/100 ft. (±1mm/10m)
Interior Range Up to 200 ft. (60m) diameter depending
upon light conditions
Exterior Range Up to 2,000 ft. (600m) diameter with
detector
Remote Range Up to 200 ft. (60m) diameter with remote
(40-6532 & 40-6539)
Self-Leveling Range ±3.5°
Power Supply Rechargeable battery pack and
6.4V charger (40-6532 & 40-6539)
4 “C” alkaline batteries (not included)
Battery Life
Approx. battery life 15 hours continuous use
with 40-6532 & 40-6539 rechargeable battery
pack; 20 hours with 4 “C” alkaline batteries
Dimensions 7.087" x 6.378" x 7.953"
(180 x 162 x 202mm)
Weight 4.409lbs (2Kg)
Working Temperature 32°F to 104°F (0°C to +40°C)
Center screw thread 5/8" – 11
Scanning Modes 0º, 30º, 60º
Rotation Speed 150, 200, 250, 300 rpm
IP Protection Class 66
