Product Manual

Table of Contents

1. Kit Contents

2. Features and Functions

3. Safety Instructions

4. Location/Content

of Warning Labels

5. Location of Parts/Components

6. Operating Instructions

7. Using the Product

8. Self-Check & Fine Calibration

9. Technical Specifications

10. Application Demonstrations

11. Care and Handling

12. Product Warranty

13. Warranty Registration

14. Accessories

15. Troubleshooting

1. Kit Contents

Description Qty.

Self-Leveling Two, Three or Five-Beam Laser Dot 1

Multi-Functional Magnetic Base 1

Mounting Strap 1

“AA” Alkaline Batteries 3

Magnetic Floor Target (40-6693, 40-6695, 40-6678) 1

Instruction Manual 1

Soft-Sided Pouch and Hard-Shell Carrying Case 1

(40-6692, 40-6693, 40-6695)

Hard-Shell Carrying Case (40-6678) 1

2. Features and Functions

• Product simultaneously projects two, three, or five laser beams

40-6695 & 40-6678 (left, right, front, up and down), 40-6693

(front, up and down) and 40-6692 (up and down).

• Magnetic dampening compensation system.

• Maintains level even when affected by vibration on the job site.

• Laser flashes and sounds an audible alarm when product is

beyond leveling range.

• Low voltage indication with power indication light flashing.

• Pendulum locking mechanism helps protect unit’s inner

mechanisms.

• Multi-functional magnetic base for attaching to tripod or any

metal surface.

• Dust and rain resistant.
