9. Technical Specifications
Laser Wavelength 635nm±10
Laser Classification Class IIIa
Maximum Power Output ≤5mW
Accuracy ±1/8"/50 ft. (±2mm/10m)
Interior Range Up to 100 ft. (30m) depending
upon light conditions
Self-Leveling Range ± 3°
Power Supply 3 “AA” alkaline batteries (included)
Battery Life Approx. 50 hours of continuous use
Dimensions 5.00" x 1.97" x 5.75"
(127 x 51 x 146mm)
Weight 1.43 lbs. (0.65 Kg)
Working Temperature 14°F to 113°F (-10°C to +45°C)
Center Screw Thread 1/4" - 20 and 5/8" - 11
IP Protection Class 54
