Johnson Controls Vibration Diagnostics Service Installation Guide
3
General precautions
• Carefully review all manuals and on-product instructions, cautions, and warnings for the equipment under test
prior to use of the WVS-1000 DAQ or mounting of the sensor cable to avoid any hazards from the equipment
under test.
• To reduce the risk of personal injury or death, thoroughly review and ensure you understand the instructions,
cautions, and warnings on the WVS-1000 DAQ and in the manual that accompany the device prior to use of
the WVS-1000 DAQ or mounting of the sensor cable.
• Incorrect use could cause personal injury from contact with rotating equipment or damage to the product and
the equipment under test. Operators should be qualified according to local, state, and national building and
safety codes and regulations.
• Use appropriate personal protective equipment and tools suited for electrical operation purposes.
• Make sure that the sensor cable is clear of any moving components on the equipment under test. Use cable
ties as necessary to ensure that the sensor cable is securely mounted to the equipment under test and will not
move during testing.
• Assess each piece of equipment under test and any potential safety concerns with the test operation. In some
instances, it is best to de-energize the equipment and let it come to rest prior to mounting the accelerometer if
the sensor is mounted close to a rotating component. Coordinate with facility representative to ensure proper
lockout tagout operations and notifications are complete before using the WVS-1000 DAQ.
• If it is necessary to de-energize the equipment under test, follow all instructions, cautions, and warnings for
shutting down the equipment under test, then open and tag all disconnected switches. Never assume electrical
power is disconnected. Check with a meter and test equipment. Some equipment under test may require
added time to fully de-energize.
• Do not touch or adjust any safety devices associated with the equipment under test. All safety features,
disengagements, and interlocks must be in place and correctly functioning. If these devices are adjusted or
tampered with in any way, serious injury or death can occur. Never bypass or wire around a safety device.
Setup and adjustments
Installing the Johnson Controls Vibration Diagnostics Service mobile application on your mobile
device
1. Download and install the Johnson Controls Vibration Diagnostics Service mobile app on your mobile device.
2. Complete the training. The training videos are accessible from the mobile app or at:
https://jcpublic.kzoplatform.com/library
3. Open the app and set up your account. Your program administrator will set up your username and password. If
you do not have this information, contact your program administrator.
Risk of Personal Injury.
To reduce the risk of serious injury or death, read these instructions thoroughly and follow all warnings and
cautions included in all manuals that accompany the product and attached to the unit.
Risque de blessure personnelle.
Pour réduire le risque de blessures graves ou de décès, lisez attentivement ces instructions et suivez tous les
avertissements et mises en garde inclus dans les manuels qui accompagnent le produit et qui sont joints à l’unité.
