Purpose of control Operating control
Construction of control and
whether the control is electronic
In-line
Type 1 or Type 2 Type 1
External pollution situation Pollution degree 2
Rated impulse voltage 330 V
Ball pressure temperature 176°F (80°C)
External power supply 5 VDC; 1200 mA, SELV, Class 2; Low power (<15 W)
Battery disposal instructions The battery must be removed from the control before it is scrapped. Dispose of the
battery safely.
Dimensions (HxWxD) 4.76 in. x 3.07 in. x 0.98 in. (121 mm x 78 mm x 25 mm)
Weight 0.37 lb (166 g)
Housing material Polycarbonate
Compliance United States UL Listed, File 60730-1, CCN XAPX, Under UL60730-1
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
Wireless: FCC ID Grant, Part 15, Subpart C
Canada Industry Canada, ICES-002, Class A
Wireless: Industry Canada, ICES ID Grant, RSS-247
Europe CE Mark – Johnson Controls declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Australia and
New Zealand
RCM Mark, ACMA, AS/NZS 61000-6-3 Emissions
Johnson Controls Vibration Diagnostics Service
Patents: http://jcipat.com.
