M9220-GGx-3 Proportional Electric Spring Return Actuators Installation Instructions12
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners. © 2009 Johnson Controls, Inc.
Building Efficiency
507 E. Michigan Street, Milwaukee, WI 53202
Mechanical Connections Standard
Shaft Clamp
Included with
Actuator
1/2 to 3/4 in. or 12 to 19 mm Diameter Round Shafts, or
3/8 and 1/2 in. or 10, 12, and 14 mm Square Shafts
Optional
M9220-600
Jackshaft
Coupler Kit
3/4 to 1-1/16 in. or 19 to 27 mm Diameter Round Shafts, or
5/8 and 3/4 in. or 16, 18, and 19 mm Square Shafts
Aluminum Enclosure NEMA 2 (IP54) for All Mounting Orientations
Ambient Conditions Operating -40 to 131°F (-40 to 55°C); 90% RH Maximum, Noncondensing
Storage -85 to 185°F (-65 to 85°C); 95% RH Maximum, Noncondensing
Dimensions See Figure 1.
Compliance United States UL Listed, CCN XAPX, File E27734; to E60730-1A: 2003-08, Ed. 3.1,
Automatic Electrical Controls for Household and Similar Use; and UL
60730-2-14: 2002-02, Ed. 1, Part 2, Particular Requirements for Electric
Actuators.
Canada UL Listed, CCN XAPX7, File E27734; to E60730-1:02-CAN/CSA: July
2002, 3rd Ed., Automatic Electrical Controls for Household and Similar
Use.
Europe CE Mark, EMC Directive 89/336/EEC (All Models)
CE Mark, Low Voltage Directive 73/23/EEC(M9220-GGC-3 Model)
Australia and
New Zealand
C-Tick Mark, Australia/NZ Emissions Compliant (All Models)
Shipping Weight 6.4 lb (2.9 kg)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
M9220-GGx Proportional Electric Spring Return Actuators (Part 2 of 2)
