User Manual

8 WRS-TTx Series Radio Frequency (RF) Wireless Transmitters Installation Instructions
Technical Specifications (Cont.)
Adjustment
Single Temperature, Scaled °F/°C
Transmitter
Temperature Set Point
Resolution
Fahrenheit Scale Graduated in 5F° Intervals;
Celsius Scale Graduated in 2C° Intervals
Transmission Range
(Transmitter and Receiver)
500 ft (152.4 m) Maximum for Indoor Line-of-Sight;
200 ft (61 m) Practical Average Indoors
Transmissions
Every 60 Seconds (±20 Seconds)
TE-7820-0
One Zone Bus Output for Temperature, Set Point, Field Strength
Measurements, and Low Battery Indication
TE-7830-0
Two Analog Outputs for Zone Temperature and Set Point:
0 to 5 VDC, 2 mA Maximum;
Two Binary Outputs for Occupancy and Low Battery Indication:
Dry Contacts Rated for 24 VAC, 50 mA Maximum
Receiver Outputs
WRS-
RTN0000-0
One Ethernet connection for communicating Temperature, Set Point,
Field Strength Measurements, and Low Battery Indication
Transmitter
Two Expandable Wall Anchors (Preferred Mounting Method) or
Double-Sided Adhesive Foam Tape
Mounting Hardware
Receiver
Four No. 6 Sheet Metal Screws
Transmitter
0 to 122°F (-18 to 50°C)
Ambient Operating
Temperature Limits
Receiver
32 to 122°F (0 to 50°C)
Ambient Storage
Temperature Limits
(Transmitter and Receiver)
-40 to 160°F (-40 to 71°C)
Operating
5 to 95% RH, Noncondensing
Ambient Humidity Limits
(Transmitter and Receiver)
Storage
5 to 90% RH, Noncondensing
Transmitter
NEMA 1 White Plastic Housing
Materials
Receiver
Gray Plastic Housing with UL94-5VB Flammability Rating
Intended for NEC Class 2 Connection
UL Listed, File E107041, CCN PAZX
UL94-5VB Flammability Rating (Receiver Housing is Plenum Rated per
UL 1995, Heating and Cooling Equipment)
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
United States
Transmission Complies with FCC Part 15.247 Regulations for Low Power
Unlicensed Transmitters
Transmitter FCC Identification: CB2-TMPSENS2400A
Receiver Radio Module FCC Identification: CB2-RFMOD2400A
Intended for CEC Class 2 Connection
UL Listed, File E107041, CCN PAZX7
UL94-5VB Flammability Rating (Receiver Housing is Plenum Rated per
CSA C22.2 No. 236, Heating and Cooling Equipment)
Canada
Industry Canada (Transmitter) IC: 279A-TSENS24A
Industry Canada (Radio Module) IC: 279A-RFMOD24A
Compliance
Australia and
New Zealand
Australia/NZ Emissions Compliant (C-Tick Mark)
Continued on next page . . .
