Fridge Freezer JLFFS2033 JLFFW2034 User Manual
Contents Safety information Children and vulnerable people safety General Safety Safety instructions Installation Electrical connection Use Internal lighting Care and cleaning Service Disposal Control panel Switching on Switching off Temperature regulation Sleep mode of the display Fast freeze function Setting temperature to 0°C in Zero degrees compartment Door open indicator Daily use Freezing fresh food Storage of frozen food Storage of the food in a fridge compartment Zero degrees compartment Multiflow
Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
By clients in hotels, motels, bed and breakfast and other residential type environments Keep ventilation openings, in the appliance enclosure or in the builtin structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit.
Safety instructions Installation Warning! Only a qualified person must install this appliance. • Remove all the packaging and the transit bolts. • Do not install or use a damaged appliance. • Follow the installation instructions supplied with the appliance. • Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear. • Make sure the air can circulate around the appliance.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance. • Do not touch the compressor or the condenser. They are hot. • Do not remove or touch items from the freezer compartment if your hands are wet or damp. • Do not freeze again food that has been thawed. • Obey the storage instructions on the packaging of frozen food. Internal lighting • Cut off the mains cable and discard it.
Control panel 1 2 3 4 1. Temperature scale 2. Zero degrees compartment icon 3. Fast freeze icon 4. Temperature key Switching on set temperature moves by 1 position and corresponding LED indicator lights up. Press the temperature key repeatedly until the required temperature is selected. The setting will be fixed. 1. Plug the appliance into electrical mains socket. 2. To turn on the appliance, touch the temperature key until all LED indicators light up. Switching off 1.
Only LED indicator corresponding to currently set temperature illuminates in low light. All other LED indicators are off. To deactivate this mode press the temperature key. Fast freeze function If you need to insert a large amount of warm food into fridge compartment (for example after doing the grocery shopping) or rapidly decrease the temperature in the freezer compartment to freeze fresh food quickly, we suggest activating Fast freeze function for proper food storage.
1 2 3 4 If you set a temperature to 5° C or higher, the temperature inside Zero degrees compartment will be higher than 3° C. Door open indicator If the door has been left open for approximately 5 minutes, the door open indicator activates. The temperature key and LED indicator of the currently set temperature flash. You can deactivate this indicator by closing the door or by pressing the temperature key.
Daily use Freezing fresh food The freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for a long time. To freeze fresh food activate the Fast freeze function at least 24 hours before placing the food to be frozen in the freezer compartment. Place the fresh food to be frozen in the bottom compartment. The maximum amount of food that can be frozen in 24 hours is specified on the rating plate, a label located on the inside of the appliance.
To lower the temperature in the compartment to 0° refer to a respective section in 'Control Panel' chapter. Multiflow The refrigerator compartment is equipped with a device that allows rapid cooling of food and keeps a more uniform temperature in the compartment. This device activates automatically when needed, for example when the temperature inside the appliance is high. Air filter On delivery the filter is in a plastic bag.
Hints and tips Normal operating sounds The following sounds are normal during operation: • A faint gurgling and bubbling sound from coils sound when refrigerant is pumped. • A whirring and pulsating sound from the compressor when refrigerant is pumped. • A sudden cracking noise from inside appliance caused by thermic dilatation (a natural and not dangerous physical phenomenon). • A faint click noise from the temperature regulator when the compressor switches on or off.
Hints for storage of frozen food To obtain the best performance from this appliance, you should: • make sure that the commercially frozen foodstuffs were adequately stored by the retailer; • be sure that frozen foodstuffs are transferred from the foodstore to the freezer in the shortest possible time; • not open the door frequently or leave it open longer than absolutely necessary; • once defrosted, food deteriorates rapidly and cannot be refrozen; • do not exceed the storage period indicated by the food ma
Care and cleaning Warning! Refer to Safety chapters. This operation will improve the performance of the appliance and save electricity consumption. Cleaning the interior Defrosting of the refrigerator Before using the appliance for the first time, the interior and all internal accessories should be washed with lukewarm water and some neutral soap to remove the typical smell of a brand-new product, then dried thoroughly.
2. Remove all food. 3. Clean the appliance and all accessories. 4. Leave the door/doors open to prevent unpleasant smells.
Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Solution The appliance is noisy. The appliance is not supported properly. Check if the appliance stands stable. Audible or visual alarm is on. The cabinet has been recently Refer to "Door Open Alarm/Indicaswitched on or the temperature is tor" or "High Temperature Alarm/ still too high. Indicator". The temperature in the appliance is too high.
Problem Possible cause Solution Water flows inside the refrigerator. The water outlet is clogged. Clean the water outlet. Food products prevent water Make sure that food products do not from flowing into the water collec- touch the rear plate. tor. Water flows on the floor. The melting water outlet is not connected to the evaporative tray above the compressor. Temperature cannot be set. The Fast freeze or Shopping mode Switch off Fast freeze or Shopping function is switched on.
If the advice does not lead to the desired result, contact the nearest Authorised Service Centre. Replacing the lamp The appliance is equipped with a longlife LED interior light. Only service is allowed to replace the lighting device. Contact your Authorised Service Centre.
Warning! Refer to Safety chapters. 100 mm min Installation Positioning Climate class Ambient temperature SN +10°C to + 32°C N +16°C to + 32°C ST +16°C to + 38°C T +16°C to + 43°C Location It must be possible to disconnect the appliance from the mains power supply. The plug must therefore be easily accessible after installation. The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight etc.
A Green and Yellow: Earth C Brown: Live E Neutral Blue: As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: 1. Connect the wire coloured green and yellow to the terminal marked either with the letter Electrical Connection Caution! Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
Technical data Height 2005 mm Voltage 230 - 240 V Width 595 mm Frequency 50 Hz Depth 647 mm Rising time 20 h Fridge Freezer User Manual The technical information is situated in the rating plate, on the external or internal side of the appliance and in the energy label.
Repairs - after sales service Your John Lewis appliance comes with a three year guarantee. Your original receipt acts as your guarantee. Please make sure you retain it. The guarantee does not cover you against faults caused by accidental damage or misuse. For further details visit johnlewis.com/customerservices. If it is not working correctly refer to the "Troubleshooting" chapter in this user manual.
John Lewis, Southampton 02380 216 400 Knight & Lee, Southsea 02392 827 511 John Lewis, Stratford 020 8532 3500 John Lewis, The Trafford Centre 0161 491 4040 John Lewis, Watford 01923 244 266 John Lewis, Welwyn 01707 323 456 John Lewis at home John Lewis, Ashford 01233 811 010 John Lewis, Chester 01244 393 880 Fridge Freezer User Manual John Lewis, Chichester 01243 813 030 John Lewis, Croydon 020 8662 4730 John Lewis, Horsham 01403 214 740 John Lewis, Ipswich 01473 275 850 John Lewis, Newbury 01635 263 980
ENVIRONMENTAL CONCERNS marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office. Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances.
Fridge Freezer User Manual 25
Fridge Freezer User Manual
Fridge Freezer User Manual 27
0157391-A-492017 ( Subject to change without notice.
