Installation Sheet
Page 12 www.jacuzzi.com
Installation
English
This skirt installation method is used for select bathtubs only. All other Comfort Collection bathtubs utilize magnets to
secure skirt panels.
To remove the skirt panel -
Grasp an edge of the skirt panel and pull to separate.
To reinstall the skirt panel (Figure 9) -
Align the six posts on the panel with the six receptor sockets on the tub and press into
place.
Skirt Panel Adjustment (Figure 10) -
Insert a standard screwdriver into the receptor socket through the slot at the rear. Turn
clockwise to tighten and counter-clockwise to loosen.
Cleanup After Installation
To avoid dulling and scratching the surface of the bathtub, never use abrasive cleaners. For most soiled surfaces, a mild
liquid detergent and warm water is sufcient. The following is also recommended:
• Remove spilled plaster with a wood or plastic edge. Spots left by plaster or grout can be removed if lightly rubbed with
detergent on a damp cloth or sponge. Do not use metal scrapers, wire brushes or other metal tools, as they will dam-
age the bathtub’s surface.
• Paint, tar, or other difcult stains can be removed with Fantastik® or soapy water.
• Minor scratches which do not penetrate the color nish can be removed by lightly sanding with 600-grit wet/dry sand-
paper. You can restore the glossy nish to the acrylic surface of the bathtub with a special compound, Meguiar’s #10
Mirror Glaze. If that is not available, use automotive rubbing compound followed by an application of automotive paste
wax.
• Major scratches and gouges which penetrate the acrylic surface will require renishing. Call Jacuzzi Luxury Bath to
nd a service agent in your area.
Cleaning
CAUTION! Do not use oil or oil-based bathtub additives. Never use abrasive, or caustic, household cleaners
on any Jacuzzi Luxury Bath product.
If you want to use any kind of bathtub additive, use only a small amount of low-foaming powder or crystal substance; the
whirlpool action intensies the foaming properties of soaps.
The use of certain bathtub oils, bubble baths, and bathtub additives may increase the level of accumulations of bathtub
residue in the whirlpool system and may cause false reading of the water level sensors. If excess accumulations persist,
you should discontinue use of these products.
To remove accumulations of bathtub residue from the whirlpool system, it is recommended that a bathtub be cleaned
regularly. For best results, however, we recommend that you clean your whirlpool bathtub after each use using Systems
Clean™, our exclusive two-part plumbing system cleaner made specically for whirlpool bathtubs. Systems Clean™ is
available through an authorized Jacuzzi Luxury Bath Distributor or by calling us direct at 1-800-288-4002 or may be pur-
chased online at www.jacuzzi.com.
Fig. 9
Receptor Socket
Post
Fig. 10
Interior View
Exterior View
Receptor Socket Slot
Skirt Panel Installation (Select Skirt Models Only)
