Technical Specifications

Jabra.com/Eliteactive45e
Jabra Elite Active 45e – Technical Specifications
Specifications
Jabra Elite Active 45e
Engineered for wireless music, calls and sport.
Waterproof durability
*
and superior fit.
• Comfortable, secure earbuds with Earwings and Earhooks
• IP67-rated waterproof durability with 2-year sweat and dust warranty**
• Run safely with an earbud design to keep you aware of the surroundings
• Up to 9 hours battery on a single charge
• 2-microphone call technology for superior calls
• One-touch access to Amazon Alexa***, Siri®, and Google Assistant™
© 2019 GN Audio A/S. All rights reserved.
® Jabra is a registered trademark of GN Audio A/S.
The Bluetooth
®
word mark and logos are registered trademarks owned by the
Bluetooth SIG, Inc. and any use of such marks by GN Audio A/S is under license.
Jabra Elite Active 45e Techspec/01/2019
Audio Ambient and wind noise reduction for calls Yes (2 microphone noise reduction technology)
Customized Call EQ 3 default equalizer settings
Speaker size φ12.0 *4.7
Speaker sensitivity 107dB±3dB
Speaker impedance 16 ohm
Speaker max input power 10mW
Speaker frequency range 20Hz-14KHz
Speaker bandwidth Music mode A2DP
Speaker bandwidth Speak mode HFP
Microphone type MEMS
Microphone sensitivity -38 dBV (94 dB SPL @ 1 kHz)
Microphone frequency range 20Hz-20KHz
Microphone bandwidth 100Hz-8KHz (Wideband)
Headset bandwidth 1M Hz
Fit & Comfort Form factor Wireless In Ear
Secure fit The adaptable Earhook and the Earwing make sure the headset stays fit and secure on the head
Earhooks Yes, customizable for perfect fit
Earwings Yes
Eargels Open design, keeps you aware of the surroundings
Multi-function button Power on/off (hold), play/pause music, answer/end call, bluetooth pair (hold)
Battery Talk time Up to 9 hours
Standby time Auto off after 15 min without connection, and 60 min without activity. >73hrs
Charging time, dedicated USB wall charger
(500mA)
Full charge in 120 minutes
Quick charge 15 minutes charging equals 1 hour of battery
Connectivity Connectivity Bluetooth (R)
Connection (mini jack, USB, etc) Micro USB (charging only)
Supported Bluetooth profiles HSP/HFP/A2DP/AVRCP/PBAP/GATT
Bluetooth compliance Bluetooth
®
5.0
Bluetooth wireless technology Bluetooth
®
5.0
Operating range from device Up to 10m
Multiple device pairing Up to 8, two devices can be connected simultaneously
General What’s in the box Earbuds, USB cable, accessory box, quick start guide and cover page
Operating temperature 0°C - 45°C
Storage temperature -20°C - 85°C
Features IP67, 9 hours battery, Open acoustic design, Windnoise protection
Packaging dimensions (LxWxH mm) Case: 390*300*211, Unit:124*55*187.4
Main unit dimension (LxWxH mm) 40 x 10.5 x 12
Gross weight (with cable) 29g
Net weight (without cable) 23.4g
Materials used (outside) PC/ABS plastic. Silicon rubber. TPEE/TPE
Neckband material TPE
Pairing PIN, if applicable 0000
Charging plug dimensions uUSB
Warranty** IP67-rated waterproof design, with 2-year warranty against sweat and dust
Certifications Bluetooth
®
5.0, CE, FCC, IC, RoHS, REACH, TIA-810-B, TIA-920.130-A
*The Elite Active 45e earbuds are IP67-verified to withstand fresh water up to one meter for 30 minutes
** Registration required with Jabra Sound+app
***Operating system dependent
