4.5.8 JUSTwoot! Setting
Ź

$0'2YHUFORFNLQJ&RQ¿JXUDWLRQ
7KLVLWHPDOORZV\RXWRVHWSURFHVVRUIUHTXHQF\SURFHVVRUYROWDJH&381%+7OLQNVSHHGQF+7
LQFRPLQJOLQNZLGWKQF+7RXWJRLQJOLQNZLGWKPHPRU\FRQ¿JXUDWLRQDQG&38+7UHIHUHQFH
clock.
7KHRSWLRQRI&38+75HIHUHQFH&ORFNDOORZV\RXRYHUFORFN&38FORFNWKH0LQLV0+]WKH
0D[LVNH\LQWRVHOHFWFORFN
BIOS SETUP UTILITY
Main Advanced Boot Security Power JUSTw00T! Exit
OverClock Settings To Enabled/Disable
Onboard PCIE LAN BOOTR
ĕ 
Select Screen

ĖĘ 
Select Item

Enter Go to Sub Screen

F1 General Help

F10 Save and Exit

ESC Exit
Ź
AMD Overclocking Configuration
Ź
DRAM Timing ConFiguration
Ź
Memory Configuration
Memory CLK :N/A,533MHZ
CAS Latency(Tcl) :N/A,7 CLK
RAS/CAS Delay(Trcd) :N/A,7 CLK
Row Precharge Time(Trp) :N/A,7 CLK
Min Active RAS(Tras) :N/A,20 CLK
RAS/RAS Delay(trrd) :N/A,4 CLK
Row Cycle (Trc) :N/A,27 CLK
CPU Voltage Control [Auto]
Vcore :1.352V
CPUNB Voltage Control [AUTO]
Dram Voltage Control [AUTO]
Dram Voltage :1.542V
NB Voltage Control [AUTO]
NB Voltage :1.160V
SB Voltage control [AUTO]
SB Voltage :1.248V
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
