User Manual

Thanks for choosing the JTECH-4KSP2 18G Splitter, which can distribute one
HDMI input to two outputs. The splitter supports HDMI video resolution up to
4K@60Hz 4:4:4 and supports passing EDID information from the display, there is a
built-in Down-scaling setting can be selected by the 2-pin DIP switch on the front
panel. Moreover, the splitter supports convenient firmware upgrade through Micro-
USB port.

1x 18G Splitter

1x Power Adapter (5V DC 1A)

1x User Manual
 Supports up to 4K/60Hz 4:4:4, HDR10 and Dolby Vision.
 HDCP 2.3 compliant.
 Built-in signal equalizer, provides capability to use longer range HDMI cable.
 EDID copy priority follows Output1>Output2.
 Supports 4K to1080p down-scaling up to all outputs.
 Scaler mode selection by front panel 2-pin switch.
 Convenient firmware upgrade.
INTRODUCTION
PACKAGE LIST
1
FEATURES
