Auger (Continued)
Item # Description Part # Qty.
10 Lower Tube Weldment JM0003001 1
11 Cleanout Door Weldment JM0003016 1
12 Hydraulic Motor w/ Pinhole in Shaft (No Key) JM0001983 1
13 3/8-16 X 1 1/2 Grade 5 Zinc Carriage Bolt JM0001638 2
14 Field Light ASM JM0001881 1
15 Support Stand Weldment JM0002212 1
16 3/8 USS Flat Washer JM0003061 6
17 Hopper Safety Grate JM0002990 1
18 3/8-16 X 1.0 Grade 5 Zinc Carriage Bolt JM0001632 4
19 M6-1 X 20 Grade 8.8 Hex Bolt JM0002120 4
20 Hopper Tarp Support Tube JM0003019 1
21 Rubber Pipe Caps 1.0 ID JM0002785 2
22 Hopper Lock Weldment JM0002967 1
23 Rubber Handle Cap JM0002784 2
24 0.375 Shaft Dia 1.125 OD Steel Ball Bearing JM0001828 2
25 Hopper Tarp Side Clamp JM0003020 2
26 Cleanout Door Threaded Knob JM0001984 2
27 Hopper Pivot Bar JM0002786 1
28 Support Stand Spring Plunger JM0002789 1
29 Hopper Handle Bearing Mount JM0002220 2
30 3/8-16 X 2 1/2 Grade 5 Zinc Hex Bolt JM0001647 2
31 3/8-16 X 1.0 Grade 5 Zinc Hex Bolt JM0001592 2
32 1/4-20 X 3/4 Grade 5 Zinc Hex Bolt JM0001507 9
33 1/4-20 Grade 5 Zinc Serrated Flange Hex Nut JM0001630 9
34 3/8-16 X 3/4 Grade 5 Zinc Hex Bolt JM0001663 4
35 3/8-16 Grade 5 Zinc Serrated Flange Hex Nut JM0002152 12
36 1/2-13 X 1 1/4 Grade 5 Zinc Hex Bolt JM0001513 2
37 1/2-13 Grade 5 Zinc Centerlock Hex Nut JM0001511 2
38 3/8-16 X 1 3/4 Grade 5 Zinc Hex Bolt JM0002097 2
39 3/8-16 Grade 5 Zinc Centerlock Hex Nut JM0001512 9
40 3/8-16 X 1 1/2 Grade 5 Zinc Hex Bolt JM0001659 4
41 3/8-16 X 2 1/4 Grade 5 Zinc Hex Bolt JM0001660 1
42 3/8 Zinc Lock Washer JM0001661 4
43 Bolt Flange Bearing JM0001811 1
44 2" Wide Auger Hold Down Ratchet JM0003084 1
45 3/8-16 X 1.0 Grade 5 Zinc Serrated Flange Hex Bolt JM0002092 1
46 M6-1 Grade 8.8 Nylon Locking Hex Nut JM0002167 4
47 1/2-13 Grade 5 Zinc Hex Nut JM0002124 2
48 1/2-13 Acorn Nut JM0001772 2
49 1.0 OD 0.515 ID X 0.35 Long Black UV Nylon Spacer JM0001962 2
50 Telescoping Spout JM0010306 1
51 8” Dia. Clamp JM0002870 1
52 M10 X 1 1/2 L Bolt with Plastic Cap JM0001966 1
53 3/8-16 Zinc J-Bolt JM0001519 1
54 3/8-16 Grade 5 Zinc Hex Nut JM0001707 2
