Users Manual

ManualsBrandsJ&C ELEVEN ManualsAudio EquipmentBluetooth headset

Table Of Contents

DC 5V interface

Easy pairing connection Charging schematic Product schematic diagram

Product speciﬁcations

Wear schematic

IOS

Android

Indicator light

①The earphone is taken out of the package and placed in thecharging compartment. The

earphone is charged and activated,and the redlightis on.

②The headphones are taken out of the charging bin, the host red and blue lights alternately

ﬂashing, and the blue lights slowly ﬂashing, that is, the pairing of ears is successful.

③Open the phone bluetooth

Search Wireless name: SKY PLUS S11

Click Connect

Bluetooth

SKY PLUS S11

connected

Note: If the left and right headset do not connect within 1 minute,headset will

enter standby mode, if necessary please turn oﬀ the headset and follow the

above steps to connect.

④ After the headset is used, put it directly into the charging box

and the headset turns oﬀ.

⑤To use the headset again, simply remove the headset from the

charging box.

The headset will automatically complete the binaural pairing and

connect the phone.

Call/ Play: about 5

Standby: about 150

Up to

hours

times:

Mobile charging

Charging box

Headset

Packing List

When charging: White light ﬂashing

Full power: white light is always on

Charging time: about 1 hour

When charging: red light is always on

Full power: The red light turns blue for

about 30 seconds before the light goes

out

Charging time: about 1 hour

▲Note: When charging the product charging box, please use our standard

charging cable, 5V/ 1A charger.

Special Note: Do not use more than 5V/ 1A fast charge charger, so as not

to damage the charging box!

Bluetooth headset

(left and right)

Headset power box

USB charging cable

User's Guide

Beautiful packaging

Bluetooth connection name: SKY PLUS S11

Bluetooth version:5.0

Power Input: DC 5V

Headset Battery capacity: 3.7V/ 50mAh

Call/ play time: about 4 hours (Hours)

Charging time: about 60 minutes (Min)

Charge box battery capacity: 3.7V/ 300 mAh

Support agreement: HSP / HFP /A2DP / AVRCP

Sensitivity: 120 士 5dB

Frequency response range: 20-20000Hz

Impedance: 16Ω

Product Name: SKY PLUS S11

Wireless 5.0 More compatible

Compatible with Apple IOS and Android smartphones

Rich functions, one-button control

Function button

Magnetically suction charger

Power button

Midhead Port

Ear storage bin

1.Call SIRI:Double touch the home button on the left and right headphones

2.Play/pause: short touch the left/right earphone HOME button in the

music state

3.Next/Last song: Touch the earphone's HOME button in the music state for

1 second

4.On/oﬀ: take out boot/put back shutdown/long press HOME 5 seconds

5.Answer calls: short touch the left/right earphone HOME button when

an incoming call is received

6.End of call: short touch the left/right earphone HOME button during

the call

7.Reject call: Touch the earphone's HOME button for 1 second when an

incoming call is received

Note:Volume increase or decrease in mobile phone operation

Summary of content (2 pages)

PAGE 1
Easy pairing connection Wireless 5.0 More compatible Compatible with Apple IOS and Android smartphones ①The earphone is taken out of the package and placed in thecharging compartment. The earphone is charged and activated,and the redlightis on. ②The headphones are taken out of the charging bin, the host red and blue lights alternately ﬂashing, and the blue lights slowly ﬂashing, that is, the pairing of ears is successful. IOS Android Rich functions, one-button control L Function button R 1.
PAGE 2
FCC Requirement changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
