Assembly
(cont’d)
Step 3
–
Axle Ass
embly
•
Insert axle through re
ar
brackets and tow bar.
•
Torque
rear bracket b
olts from Step 2 to
20
Ft.
-
Lbs.
Tools Needed
•
1/2” wrench
•
Torque wrench
Torque bolts to
20 Ft.-Lbs.
Axle
1
...
...
11
12
13
14
15
...
...
50
