Product Manual

Page 6 of 12
Specific Operation Warnings
⚠WARNING
 Do not exceed the rated pressure of 90 PSI.
 Do not point nozzle at people or animals.
 Always hold on to the hose while rewinding to prevent the hose whipping.
 Not for use by or around children.
Main Parts of Hose Reel
Part#
Description
Qty.
Part#
Description
Qty.
1-1
Small Gear
1
16
Swivel Body
1
1-2
Roller Frame B
1
17
Plug
1
1-3
Moving Unit
1
18
Retainer
1
1-4
Roller
2
19
O-Ring
2
1-5
Roller Frame B
1
20
Swivel Spool
1
1-6
Taxis Axle
1
21
Screw
4
2
Right Casing
1
22
Synchronous Belt Wheel
1
3
Left Casing
1
23
Synchronous Belt Wheel Guard Plant
1
4
End Cover
2
24
Drum
2
5
Handle
1
25
Screw
4
6
Screw
21
26
Gear
1
7
Hose Assembly
1
27
Ring
1
8
Base
1
28
Guard Plant
6
9
Screw
4
29
Screw
8
10
Main Shaft
1
30
Screw
3
11
Bumper Block
1
31
Washer
2
12
Hose Assembly
1
32
Ratchet Paw
1
13
Spring
1
33
Synchronous Belt
1
14
Clamp
1
34
O-Ring
1
15
Hose Clamp
2
Assembly Instructions
1) For mounting, install the reel on the wall 4.5 feet (1.5m) above the floor, at the most.
2) The reel base has two mounting holes for mounting on a suitable, flat surface for air series (four
mounting holes for water series). The following illustration can be used as a guide for mounting
holes in the base.
3) Using the mounting holes in the base, mount the reel in the desired location. Be sure to use the
appropriate hardware and tighten securely.
