Intended Use
The Ironton 12V Oil Extractor Pump is ideal for quick and clean oil changes. Simply connect the oil
extractor’s clamps to the vehicle’s 12V car battery. The oil is simply drawn out the motor through the
oil dipstick bore. It works with motor, diesel, or heating oil.
Packaging Contents
 Part A (5)
 Suction Probe (1 pc)
 Suction Connector (1 set)
 Drain Connector (1 set)
 Extraction Pump (1 pc)
 10mm Hose (1 set)
Technical Specifications
Property
Specification
Motor
12 Volt DC
Power Draw
Approximately 5 Amps
Max. Flow
250 liters/hour (66 GPH)
Duty Cycle
30 minutes
Important Safety Information
⚠WARNING
 Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
 The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
 Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
 Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
 Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
