Specification Sheet

Items to Note:
Page 3 of 3
Electrical Requirements for AE-42
Unit requires 115/120v, 15 amp. supply line. Pigtails are
provided in the bottom of wire raceway for hookup to
supply line. Make entrance into knockout provided in top
of raceway through le-hand vent hole.
Installation Types
Recessed
Placed into the wall, between 16” on center studs,
protruding 3 7/8” into the room. It is recommended to
attach a 2” x 4” cleat to studs, level with bottom of the
opening to support cabinet when installing.
Surface Mount
Installed directly onto the wall, with no cutout, centered
and anchored on secure stud. Will protrude 7 3/4” into
room. Optional surface mount kit is available to finish
sides of unit and recommended for complete installation.
Recommended Standing Room Clearance
Be sure to check that you have adequate standing space
(at least 24”) to stand beside the ironing board to iron.
Installation Heights
Use the provided Installation Height Chart on page 1
to determine your desired ironing board height, making
note of the two height positions of the board. The
Desired Ironing Board Height is the first position the
board is automatically placed when first lowering the
board. The Adjusted Position is 4” higher and can be
engaged aer the board has been fully lowered.
Swivel
Swivel feature allows board to turn 90° in either direction,
for a full 180° swivel, with five locking positions.
Door
Ironing center comes standard with a flat maple veneer
door and a variety of additional door options. Door
opens approximately 180°, flush against the wall. Please
be sure to allow 16” to the side of unit for the door to fully
open.
Hinge Side
Unit comes standard with the hinge on the right. A le
side hinge can be requested when placing order.
Unfinished Cabinet
The exterior of the cabinet is unfinished and ready to be
painted or stained to match existing decor.
Questions?
Give us a call at 1-800-536-9495
or email [e-mail]
