Operation Manual
Table Of Contents
- 1. Introduction
- 2. Using the Scanner Properties Dialog Box (Setup)
- 2.1 A Glance at the Scanner Properties Dialog Box
- 2.2 Buttons on the Scanner Properties Dialog Box
- 2.3 The Image Tab
- 2.4 The Compression Tab (Windows PC only)
- 2.5 The Color Dropout Tab
- 2.6 The Paper Tab
- 2.7 The Preview Tab
- 2.8 The Options Tab
- 2.9 The Setting Tab
- 2.10 The Imprinter Tab
- 2.11 The Information Tab
- 3. Legal Information
Setting
Show Scanning Progress：No
Show Warning Message：No
Imprinter
None
2.3 The Image Tab
The Image tab allows you to choose the front side and (or) the rear side of your document, the
type of image, andconfigure several basic scan settings. Note that except for the resolution, you
can set individual scan settings for the front side and the rear side. For example, all settings in
the Image tab, Compression tab and Color Dropout tab can be set individually for the front and
the rear side. However, the settings in the Paper tab, the Options tab (Rotation, Separation,
Enhancement), and the Settings tab have to be the same for the front and rear side.
The Image tab dialog box
