CHAPTER 1: INTRODUCTION
2003 IPMobileNet, Inc. 9 IPSeries MR User Manual / Rev. A / 04-September-03
Product Specifications
TABLE 4: PRODUCT SPECIFICATIONS
G ENERAL S PECIFICATIONS
PARAMETER Specification IP100 Specification IP400 Specification IP800
frequency range 135 to 175 MHz 400 to 512 MHz 806 to 869 MHz
channel spacing / speed
12.5 kHz / 9600 bps
25.0 kHz / 19200 bps
12.5 kHz / 9600 bps
25.0 kHz / 19200 bps
12.5 kHz / 9600 bps
25.0 kHz / 19200 bps
mode of operation full-duplex, diversity reception full-duplex, diversity reception full-duplex, diversity reception
operating temperature range -30C to +60C (-22F to +140F) -30C to +60C (-22F to +140F) -30C to +60C (-22F to +140F)
power supply voltage 13.8 VDC +/-20% 13.8 VDC +/-20% 13.8 VDC +/-20%
power supply <1 amps receive <1 amps receive <1 amps receive
current consumption 16 amps transmit 13 amps transmit 8 amps transmit
number of channels 256 256 256
intelligent diversity reception triple receiver, diversity reception triple receiver, diversity reception triple receiver, diversity reception
antenna connections
four (4) type N jacks
(tx, rx1, rx2, rx3)
four (4) type N jacks
(tx, rx1, rx2, rx3)
four (4) type N jacks
(tx, rx1, rx2, rx3)
interface connection
RS232 serial port connector or
RJ45 Ethernet 10 Base T
RS232 serial port connector or
RJ45 Ethernet 10 Base T
RS232 serial port connector or
RJ45 Ethernet 10 Base T
dimensions (HxWxD / lbs) 1.75” X 19” X 8.2” / 9.5 lbs 1.75” X 19” X 8.2” / 9.5 lbs 1.75” X 19” X 8.2” / 9.5 lbs
regulatory FCC Part 90 and Part 15 FCC Part 90 and Part 15 FCC Part 90 and Part 15
IP TRANSMITTER SPECIFICATIONS
PARAMETER Specification IP100 Specification IP400 Specification IP800
frequency stability +/- 2.4 ppm @ operating temp +/- 1.5 ppm @ operating temp +/- 1.0 ppm @ operating temp
emission designator 20KF01D 20KF01D 20KF01D
spurious and harmonic -61 dBc max -59 dBc max -56 dBc max
transmit power 60 watts 40 watts 20 watts
transmit attack time less than 5 ms less than 5 ms less than 5 ms
IP RECEIVER SPECIFICATIONS
PARAMETER Specification IP100 Specification IP400 Specification IP800
sensitivity (voice)
12.0 dB SINAD@
-119 dB max level
12.0 dB SINAD@
-118dB max level
12.0 dB SINAD@
-118dB max level
distortion less than 3% @ 1.0 kHz less than 3% @ 1.0 kHz less than 3% @ 1.0 kHz
spurious response 85 dBm minimum 85 dBm minimum 85 dBm minimum
intermodulation distortion 75 dB minimum 75 dB minimum 75 dB minimum
